Pellet boiler BioPel Mini Plus CA 15 kw

-10% puidugraanuli-katel-pelletikatel-opop-biopel-mini-tower-plus
puidugraanuli-katel-pelletikatel-opop-biopel-mini-tower-plus
puidugraanuli-katel-pelletikatel-opop-biopel-mini-tower-plus
puidugraanuli-katel-pelletikatel-opop-biopel-mini-tower-plus-20e
puidugraanuli-katel-pelletikatel-opop-biopel-mini-tower-plus-20k
puidugraanuli-katel-pelletikatel-opop-biopel-mini-tower-plus-20t
puidugraanuli-katel-pelletikatel-opop-biopel-mini-tower-plus
Power output 15kW
Perfect for up to 200m2
ECO series A+ (efficiency: 93,7%)

Pellet boiler BioPel MINI Plus product line is described as most efficient and care free boiler series by OPOP. Small dimensions give everyone the opportunity to install boiler even in the smallest rooms.
4584,76 €
4126,28 €

Pellet boiler BioPel MINI Plus is the most carefree boiler on the market. Fully automated cleaning system allows you to have long periods between overall maintenance. Small dimensions gives you the opportunity to install boiler even in the smallest boiler rooms. Easy access to the burner and the boiler exchanger ensures simple and fast boiler maintenance. The equipment's eco-friendly nature is due to very low emissions (given the A+ emission class 5). A wide range of accessories can increase the operation and control automation of entire heating system in your house.

Remotely monitoring your heating with your mobile phone, gives you an overview of the temperatures in the house and the condition of heating system regardless of where you are. Be noted that internet module is already integrated into every BioPel MINI Plus boiler!

This BioPel MINI Plus series provides high comfort in pellet heating and allows very simple control of the control unit. The control unit is equipped with a touch screen, allowing to set and change all parameters easily. For example solar collector unit, heating control based on the outdoor temperatures, room thermostats, 2 different heating circuits (i.e underfloor and radiators), lambda sensor, external larger pellet container work etc.

Leaflet:


Set includes:

* Pellet boiler
* Pellet burner 15kw
* Automated bottom ash removal system
* Compressor cleaning for heat exchanger and burner head
* Touch screen control panel V9
* Touch screen room thermostat RT-10
* Compact pellet hopper 150kg or 2m long auger for separate pellet hopper (click here)

Technical data for BioPel MINI 15:

Nominal output kW 15
Minimal output kW 4,7
Fuel (wood pellet) mm 6-8
Fuel consumption kg/h 1,01-3,36
Emission class   5 / Ekodesign
Efficiency % 93,7
Water volume L 32
Required chimney draught Pa 7,5
Maximum pressure Bar 2
Maximum heated temperature C 80
Minimum return temperature C 55
Weight kg 160
B Height mm 1088
H Width mm 352
J Depth mm 1043
E Fume duct location mm 281
G Total depth with automatic ash removal mm 1162
F Total depth with hydraulic set mm 1212
O Outlet water funnel from the ground  mm 822
L Fume duct position from the ground mm 739
N Inlet water funnel location from the ground mm 156
M Release valve position from the ground mm 145
P Inlet water funnel location from the fume duct mm 106
Q Outlet water funnel location from the fume duct mm 106
R Flue pipe diameter mm 130
X Boiler width with handrail mm 406
Connecting outlets DN G1 1/4"
